Schenider Electric Harmony XD4 PA22 manipulator 2 directions (IA1)

Harmony XDA

Controller joystick complete

XD4

Chrome-plated metal

Zamak

22 mm

1

Pulse in the " 0 " position, the drive shaft 54 mm length

3 positions

2 directions

1 NO

Slow break

Screw terminal : <= 2 x 1.5 mm2 with cable end conforming to EN 60947-1
Of the screw terminals : > = 1 x 0.22 mm2 without cable end conforming to EN 60947-1

0,116 kg

7000000 Pa at 55 °C,distance: 0.1 m

Circular

1

Standard

Without

1000000 cycles

0.8...1.2 Nm conforming to EN 60947-1

Head to the cross head compatible with Philips no 1 screwdriver
Head to the cross head compatible with pozidriv No 1 screwdriver
Slotted head compatible with flat Ø 4 mm screwdriver
Slotted head compatible with flat Ø 5.5 mm screwdriver

Silver alloy (Ag/Ni)

10 A fuse cartridge type gG conforming to EN/IEC 60947-5-1

10 A conforming to EN/IEC 60947-5-1

600 V (degree of pollution: 3) conforming to EN 60947-1

6 kV conforming to EN 60947-1

0.1 A at 250 V, DC-13, R300 conforming to EN/IEC 60947-5-1
0.22 A at 125 V, DC-13, R300 conforming to EN/IEC 60947-5-1

1000000 cycles, AC-15, 2 a AT 230 V, operating range: 3600 cycles/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, AC-15, 3 a AT 120 V, operating range: 3600 cycles/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, AC-15, 4 A at 24 V, operating range: 3600 cycles/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13, 0.2 a AT 110 V, operating range: 3600 cycles/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13, 0.5 a AT 24 V, operating range: 3600 cycles/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C

Λ < 10exp(-6) at 5 V, 1 mA in clean environment conforming to EN/IEC 60947-5-4
Λ < 10exp(-8) at 17 V, 5 mA in clean environment conforming to EN/IEC 60947-5-4
