SCHNEIDER TESYS LE1D09N7 Motorstarter 9A-415V (ARM 6/3)
2665/DD4/SX/Q1+1plast rov
Nuovo (Altro)
7,00 € tax incl.
tax incl.
1 Item
Warning: Last items in stock!
| Tipo | Relè |
| Description of the conditions | Senza confezione originale |
| Brand | Schneider Electric |
| Modello Librio | CA3KN22BD |
| Fabbricante | Schneider Electric |
| Responsabile dei Prodotti | Schneider Electric |
SCHNEIDER TESYS LE1D09N7 Motorstarter 9A-415V
| range |
TeSys
|
|
|---|---|---|
| product name |
TeSys LE
|
|
| device short name |
LE1D
|
|
| product or component type |
Enclosed DOL starter
|
|
| device application |
Standard
|
|
| 'utilisation category |
AC-3
|
|
| device composition |
Thermal overload relay to be ordered separately
Contactor |
|
| control type |
Push-button start green I
Push-button stop/reset red O |
| [Ie] rated operational current |
9 A AC-3
|
|
|---|---|---|
| motor power kW |
4 kW at 380/400 V AC 50/60 Hz
4 kW at 415 V AC 50/60 Hz 4 kW at 440 V AC 50/60 Hz 2.2 kW at 220/230 V AC 50/60 Hz 5.5 kW at 500 V AC 50/60 Hz 5.5 kW at 660/690 V AC 50/60 Hz |
|
| [Ithe] conventional enclosed thermal current |
9
|
|
| [Uc] control circuit voltage |
415 V AC 50/60 Hz
|
|
| cable entry number |
2 cable entry : ISO20 top
2 cable entry : ISO20 bottom 2 cable entry : Pg 13 bottom 2 cable entry : Pg 16 bottom |
|
| width |
88 mm
|
|
| height |
166 mm
|
|
| depth |
128.5 mm
|
|
| product weight |
0.92 kg
|
| material |
Polycarbonate
|
|
|---|---|---|
| IP degree of protection |
IP65 conforming to IEC 60529
|
|
| IK degree of protection |
IK07 conforming to IEC 60529
|
|
| standards |
IEC 60947-4-1
|
|
| ambient air temperature for operation |
-5...40 °C
|
|
| environmental characteristic |
Standard environment
|
